Area of Refuge Sign

AREA OF REFUGE and AREA FOR ASSISTED RESCUE — the tactile sign at the door, directional signs with the accessibility symbol, and the posted instructions.

Area of Refuge Sign: Instructions — posted in the area sign
Loading sign…
Open PNGDownload PNG
Customize

PNG output: 3000 × 2000 px

Details
Size
432 × 288
kind
instructions
header
AREA OF REFUGE
text
IF YOU CAN USE THE STAIRS, EXIT NOW|UNLESS YOU ARE ASSISTING OTHERS.|IF YOU CANNOT USE THE STAIRS|1. PRESS THE CALL BUTTON|2. TELL US WHERE YOU ARE|3. WAIT HERE - HELP IS ON THE WAY
color
blue

Public domain · License & reuse →

📍 Quick presets

About the Area of Refuge Sign

An area of refuge (or, in buildings with sprinklers where the code allows, an area for assisted rescue) is a protected place where someone who can't use the stairs waits for help during an evacuation. The 2010 ADA Standards (§216.4.2, §216.4.3) and the International Building Code (IBC 1009.9–1009.11) call for three kinds of sign: a tactile sign at the door that reads AREA OF REFUGE or AREA FOR ASSISTED RESCUE with the International Symbol of Accessibility; directional signs with the symbol pointing the way where the area isn't obvious; and instructions posted in the area telling people to use the stairs if they can and explaining the two-way communication system. Edit the instructions to match your building's system and evacuation plan.
